Related Articles
Digi-Star Amp Load Cell Cable
Crown 2-Pin Power Cable
Crown 2 PIN 12v DC Power Connector PIN Color Description A RED or WHITE + 12 V DC B BLACK GROUND The wire colors inside the indicator are opposite of the chart above.
8-pin Amp Connector to CP130 (Digi-Star Indicators) Cable
Pin 2 Orange Pin 3 Yellow Pin 6 Green Photo of Cable above
Crown 4-Pin Load Cell Cable
CROWN 4-PIN CONNECTOR WIRE ILLUSTRATION PIN COLOR A WIRE BRAID B RED C BLACK D WHITE NOTE: 4 PIN Load Cells/Weigh-Bars can not be intermixed with 5-PIN Load Cells. They can, however, be summed together at a junction box and utilized with a 5 PIN ...
Pin-Out for Digi-Star Autolog Sensor
The below is the pin-out for the weather pack on a Digi-Star Autolog PTO sensor/Rotation Counter Sensor. Pin A - Black Pin B - Brown Pin C - Blue Sensor to pigtail color matching Black - White Brown - Red Blue. - Black
