JM 875 GRAIN CART SCALE

JM 875 Grain Cart Scale Kit

J&M 875

Questions to be asked to identify the correct scale variation....

1. What does the hitch area look like?...
      -Is it welded directly to the "A-Frame" of the hitch area?  If yes, use variation 1 below.
                  or
      -Does it have a sleeve welded directly into the "A-Frame and swivel?" If yes, use variation 1 below.
                  or
      -Does it have an end cap secured with six bolts which provides a "bolt on sleeve" for a swivel hitch?

2. Does the grain cart have large "metric" floater tires (if it has single axles)?

3.  What year is the Grain Cart?
      -If you can not determine what year your grain cart is, refer to the pictures of the hitch below, which will provide an indicator of age.

4.  Does the Grain Cart have four sleeves welded to the underside of the axle with inside diameter of 2.88"?
      -See Variation 4 and 5 for an illustration of the sleeves.
      -According to the illustration on variation 4 and 5, you will need to measure the hole spacing in the sleeve.

5.  Does the Grain Cart have "Rice Axles?"
      -It is very important to know the year of manufacture for the RICE axle.

There are seven variations of the J&M 875 Grain Cart Scale system.  The older variant of the J&M 875 requires welding of a sleeve within the hitch area, while the current and newer variant is completely bolt on.  Special attention must be paid attention to regarding hitch identification as related to the variation of scale kit needed.


If a 5 POINT scale system is needed, SPECIAL ATTENTION MUST BE CONSIDERED regarding the hole measurement in the sleeves on the five POINT systems.  See variation 4 and variation 5 for more detail.


Variation (1) 3.75" 1999 and Older

(Click on the links in the left column to view the product pages on the website).


Kit Number
Description
7200196
Kit - J&M 875 / 2.5" Pintle Hitch / 3.75" Single Axle
7200196-1
Kit - J&M  875  / 2.5" Clevis Hitch / 3.75" Single Axle
7200196-2
Kit-  J&M  875 / 2.5" Ball Hitch / 3.75" Single Axle


Identify prior to purchasing....

- Grain Cart was manufactured in 1999 or before.

- This kit provides load cell spindles of 2.88" diameter.

Ensure your current spindle size is 2.88" Diameter.


- The hitch may be one of two different variant as shown in the images below.....

This image shows a rigid hitch welded directly to the A-Frame of the grain cart.  This requires a weld-on scale system.




This hitch shows a sleeve with a swivel hitch.  This requires a weld on scale system.




It is important to note, after installation of the scale system your hitch receiver will no longer swivel.


Please see the downloadable installation manual 7900238 for installation reference of this scale system.



Variation (2) 3.75" 2000 and Newer

(Click on the links in the left column to view the product pages on the website).

This kit is completely bolt on.  Expect installation time to take 6 hours or more.


Kit Number
Description
7200152
Kit - J&M 875 / 2.5" Pintle Hitch / 3.75" Single Axle


Identify prior to purchasing....

- Verify Grain Cart was manufactured after the year 2000.

- This kit provides load cell spindles of 3.75 diameter.
This kit can only be used with carts without metric/floater tires.  The spindle is reduced to 3.75 via a bushing insert in the spindle sleeve.   DO NOT ORDER THIS KIT IF YOU HAVE LARGE FLOATER TIRES!

- Verify your hitch style looks similar to the picture below the hitch receiver retained by six bolts to the frame of the grain cart.



Please see the downloadable installation manual 7900230 for installation reference of this scale system.



Variation (3) 4.5" 2000 and Newer (HEAVY HITCH)

(Click on the links in the left column to view the product pages on the website).

This kit is completely bolt on.  Expect installation time to take 6 hours or more.


Kit Number
Description
7200156B
Kit - J&M 875 / 2.88" Pintle Hitch / 4.5" Single Axle
7200156B-2
Kit - J&M 875 / 2.88" Ball Hitch / 4.5" Single Axle


Identify prior to purchasing....

- Verify Grain Cart manufactured after the year 2000.

- This kit provides load cell spindles of 4.5 diameter.
This kit is required if you have large metric floater tires on the grain cart.
- This kit provides a heavier 2.88" load cell shaft.

- Verify your hitch style looks similar to the picture below the hitch receiver retained by six bolts to the frame of the grain cart.



Please see the downloadable installation manual 7900230 for installation reference of this scale system.


Variation (4) 5 POINT 2012 - 2013

(Click on the links in the left column to view the product pages on the website).

This kit is completely bolt on.  Expect installation time to take 6 hours or more.


Kit Number
Description
7200554
Kit - J&M 875 / 5 POINT


Identify prior to purchasing....

- Verify Grain Cart was manufactured between the year 2012 and 2013.

- This kit provides four load cells that support the hopper on top of the axels.  Verify your grain cart has the mounting sleeves welded to the axels shown with the arrows in the diagram below...



A measurement of the hole spacing in the sleeve must be taken between the edge of the sleeve and center of the hole.  This kit supports a 3 inch hole spacing.  See figure below...


Ensure the measurement is 3 inches.

- Verify your hitch style looks similar to the picture below the hitch receiver retained by six bolts to the frame of the grain cart.



Please see the downloadable installation manual 7900402 for installation reference of this scale system.



Variation (5) 5 POINT 2014 and Newer

(Click on the links in the left column to view the product pages on the website).

This kit is completely bolt on.  Expect installation time to take 6 hours or more.


Kit Number
Description
7200566
Kit - J&M 875 / 5 POINT


Identify prior to purchasing....

- Verify Grain Cart was manufactured after the year 2014.

- This kit provides four load cells that support the hopper on top of the axels.  Verify your grain cart has the mounting sleeves welded to the axels shown with the arrows in the diagram below...



A measurement of the hole spacing in the sleeve must be taken between the edge of the sleeve and center of the hole.  This kit supports a 2 1/4 inch hole spacing.  See figure below...
Ensure the measurement is 2 1/4 inches.



- Verify your hitch style looks similar to the picture below the hitch receiver retained by six bolts to the frame of the grain cart.



Please see the downloadable installation manual 7600232 for installation reference of this scale system.








Variation (6) 3.75" RICE AXLE 2012

(Click on the links in the left column to view the product pages on the website).

This kit is completely bolt on.  Expect installation time to take 6 hours or more.


Kit Number
Description
7200567
Kit - J&M 875 / 2.88" Pintle Hitch / 3.75" RICE Axle


Identify prior to purchasing....

- Verify Grain Cart was manufactured in the year 2012.


It is very important to ensure the accuracy of the manufacture year on the rice axle kits.  Failure to properly identify the year of manufacture may result in the wrong scale kit.

- This kit provides load cell spindles of 3.75 diameter.

- Verify your hitch style looks similar to the picture below the hitch receiver retained by six bolts to the frame of the grain cart.



Please see the downloadable installation manual 7900230 for installation reference of this scale system.



Variation (7) 4.5" RICE AXLE 2013 and newer

(Click on the links in the left column to view the product pages on the website).

This kit is completely bolt on.  Expect installation time to take 6 hours or more.


Kit Number
Description
7200568
Kit - J&M 875 / 2.88" Pintle Hitch / 4.5" RICE Axle


Identify prior to purchasing....

- Verify Grain Cart was manufactured in the year 2013 or later.


It is very important to ensure the accuracy of the manufacture year on the rice axle kits.  Failure to properly identify the year of manufacture may result in the wrong scale kit.

- This kit provides load cell spindles of 4.5 diameter.

- Verify your hitch style looks similar to the picture below the hitch receiver retained by six bolts to the frame of the grain cart.



Please see the downloadable installation manual 7900230 for installation reference of this scale system.
